Grandstream Networks GXP2135

Image not found or type unknown
Figure 5: GXP2170 Idle Screen
Image not found or type unknown
Figure 6: GXP2135 Idle Screen
The following table describes the items displayed on
GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 idle screen.
Date and
Time
Displays the current date and time. It can be synchronized with Internet time
servers.
Note: For GXP2135 and GXP2170, if there’s no VPK configured with the
first VPK on the right side of the LCD screen, users can display time and
date on the top of the LCD screen (status bar) by enabling the option “Show
Date On Status Bar” under Web GUI?Settings?Date and Time.
Network
icon
Shows the status of network. It will indicate whether the network is down or
starting.
GRANDSTREAM NETWORKS
No image found
Page 21
