Handset Volume Up
Call screen icon. Handset volume is increasing
Image not found or type unknown
Handset Volume Down
Call screen icon. Handset volume is decreasing
Image not found or type unknown
Ringtone Volume Down
Call screen icon. The volume of ringtone is decreasing
Image not found or type unknown
Ringtone Volume Up
Call screen icon. The volume of ringtone is increasing
Image not found or type unknown
VOC status
Call screen icon.
OFF – VOC is off.
ON – VOC is on.
Table 12: GXP2130/GXP2140/GXP2160/GXP2170/GXP2135 LCD Icons
Error Message Indicator
When user changes configuration settings on LCD and the configuration cannot be applied for any
reason, LCD screen will pop up a window displaying an error message with information explaining why
the configuration couldn’t be saved.
http://192.168.6.130/export/screen/20170906-123256.png
Image not found or type unknown
Figure 7: Error message Example
Note: Possible error types could be Security, Privilege, PValue Validation, etc
