Figure 18: VPK – LCD Indication
The users could also edit and add VPK from LCD.
1.
To edit (fixed) VPK, press and hold the line key for about 4 seconds, a configuration window will
pop up for the user to configure.
2.
To add (dynamic) VPK, press and hold the RIGHT arrow key for about 4 seconds, a configuration
window will pop up for the user to configure.
Up to 20 modes can be supported on fixed VPK and up to 17 modes can be supported on dynamic
VPK. Each mode is indicated by a different icon on the LCD and the icon will be different when in
different status.
Please find the icon indications below for different mode of VPK.
VPK Mode State Icon
LED
Status
LINE
Unregistered
(No IM, Voice mail, No
Call Forward)
Image not found or type unknown
OFF
Registered + Idle
(No IM, Voice mail, No
Call Forward)
Image not found or type unknown
OFF
Unregistered + IM + Voice
mail
Image not found or type unknown
OFF
GRANDSTREAM NETWORKS
No image found
Page 48
