Grandstream Networks HT841

Device Manager
Ports Settings Page Definitions
FXS Profile
Call-ID:963579881-5060-1@BJC.BGI.F.GG
CSeq:2138REGISTER
Contact:<sip:1000@192.168.5.66:5060>;reg-id=1;+sip.instance="<urn:uuid:00000000-0000-1000-8000-
C074ADEAA59E>"
Max-Forwards:70
User-Agent:GrandstreamHT8411.0.5.9
Supported:path
Expires:3600
Allow:INVITE,ACK,OPTIONS,CANCEL,BYE,SUBSCRIBE,NOTIFY,INFO,REFER,UPDATE
Content-Length:0
Clicking the "Download" icon will download the whole log of the captured traces.
Clicking "Delete" will delete all the captured traces.
This tool can be useful for network administrators that wantto treoubleshoot the call ows without having to
use an external tool, for analyzing the network
Reboot
Automatic restart
This option triggeres an automatic reboot of the unit, the available options are:
● No
● Reboot everday: you can specify the reboot hour
● Reboot everyweek: you can specify the day of the week, and the hour of the day, for the reboot to take
place
● Reboot every month: you can specify the day of the month, and the hour of the day, for the reboot to take
place
Restore Factory
Reset Type
Gives the administrator the option to restore the default conguration on the HT841/HT881.
There are 3 types of factory reset:
● ISP Data Reset: All ISP (Internet Service Provider) congurations that may affect the IP address will be
reset (including WAN static IP).
● VoIP Data Reset: All VoIP-related congurations (mainly everything located on FXS/FXO page).
● Full Reset: Both VoIP and ISP-related conguration at the same time.
Note: After choosing the reset type, you will have to click the reset button for it to take effect.
General Settings
Account Registration
Prole Active
Activates / Deactivates the accounts. The FXS port conguration will not change if disabled, although the port
will not be operational, in this state, there will be no dial tone when picking up the analog phone and
making/receiving calls will not be possible.
Primary SIP Server
Congures SIP server IP address (Supports both IPv4 and IPv6 addresses) or domain name provided by VoIP
service provider. (For example: sip.mycompany.com, IPv4:192.168.5.170, or IPv6: fe80::20b:82ff:fe75:211d).
This is the primary SIP server used to send/receive SIP messages from/to HT841/HT881.
Failover SIP Server Denes failover SIP server IP address (Supports both IPv4 and IPv6 addresses) or domain name provided by
VoIP service provider. (For example: sip.mycompany.com, IPv4:192.168.5.170, or IPv6
