EN
out
prog
in
RS232
TAXXI
77
• A handheld programming device can be used
to exchange programs via the IR interface To
do so, the device must be in the TAXIMODE
and connected to power
• Press ESC to nish the TAXIMODE
Transmission of programs
Operation of handheld programming device:
1 Press PROG to select the program number
2 Press IN to read in a program
Press OUT to read out a program
3 Hold the handheld programming device
vertically over the IR interface
4 Pressing IN or OUT again will start the
transmission
A wrong transmission is shown by Er2
For further information, see the separate
operating manual “ handheld programming
device”
