9 - 36
NOTES: NORMALLY OPEN SWITCHES. MANUALLY ACTIVATED. CONTACT RESISTANCE IS 0.1 - 0.3 OHMS
RESISTANCE.
NOTES: NORMALLY OPEN SWITCH.ELECTRICALLY ACTIVATED. LARGE CONTACTS ARE 3 TO 5 OHMS
RESISTANCE. SMALL TERMINALS 0.1 TO 0.3 OHMS.
NOTES: NORMALLY CLOSED SWITCH. CONTACT RESISTANCE 0.1 TO 0.3 WHEN CORRECT.
NOTES: NORMALLY CLOSED SWITCH. 0.1 TO 0.3 OHMS RESISTANCE WHEN CORRECT.
NOTES: NORMALLY CLOSED SWITCH. 0.1 TO 0.3 OHMS RESISTANCE WHEN CORRECT.
Left and Right Presence Switch Off Run Start
Brown 12.00 12.00
White (When activated) 12.00 12.00
Hourmeter Off Run Start
Pink 12.00 12.00
White 12.00 to ground 12.00 to ground
Solenoid Off Run Start
Red (battery input lead) 12.00 12.00 12.00
Red (starter input) 12.00
Brown (input lead) 12.00
Brown (output to switches and module) 12.00 12.00
Interlock Module Off Run Start
Red 12.00
Yellow 12.00 12.00
Brown 12.00 12.00
Transmission Interlock Switch Off Run Start
Brown 12.00 12.00
Brown/White 12.00 12.00
PTO Interlock Switch Off Run Start
Brown/White 12.00 12.00
Brown 12.00 12.00
