Gravely Pro-Turn 52 - CONTROLS AND FEATURES OVERVIEW; Component Identification; Controls Overview

EN - 16
1. Fuel Tank
2. Fuel Gauge
3. Fuel Cap
4. Steering Levers
5. Hydraulic Oil Overflow Tank
6. Ignition Switch
7. Hour Meter
8.
Throttle Lever
9. Choke Control
10. Power Take Off (PTO) Switch
11. Battery
12. Mower Lift Pedal
13. Mower Deck
14. Seat Adjustment Lever
15. Parking Brake Lever
16. Bypass Valve Lever
17. Seat Release Lever
18. Rollover Protection Structure (ROPS)
CONTROLS AND FEATURES
