GrIP User’s Guide
Connecting Standard 15-Pin Controllers
1. Plug each game controller‘s 15-pin connector into one of the
MultiPort‘s 15-pin joystick sockets. If you are using only one joy-
stick, attach it to the MultiPort‘s Port A. You can connect and
disconnect 15-pin controllers without shutting down your com-
puter, but do not connect or disconnect controllers while a game is
running.
2. Move the MultiPort‘s Mode Selector switch towards the two 15-pin
sockets until the green LED on the Pass-Thru wing lights up to put
the MultiPort into Pass-Thru Mode.
This activates any attached 15-pin controllers and deactivates the
GrIP connectors. The green LED on the MultiPort‘s Pass-Thru wing
indicates that the MultiPort is in Pass-Thru Mode.
✳ You cannot use 15-pin controllers and GrIP controllers at the same time.
Chapter 2 – Connections
