TROUBLE SHOOTING:
PART LIST
PROBLEM
Vacuum not working
POSSIBLE CAUSE
1. Hopper gate not closed.
2. Cone cover not installed.
3. Hose not attached properly.
4. Engine not running at full RPM.
SOLUTIONS
1. Slide gate to closed position.
2. Install the cone cover.
3. Clear blockage or replace.
4. Set throttle control to FAST if equipped.
Part No.
1
2
3
4
5
Description
Adapter
Hose adapter
Extension vacuum hose
End cap
Handle
Q’ty
1
1
1
1
1
Part No.
6
7
8
9
10
Description
Handle grip
Vacuum nozzle
Plastic ring
Hex bolt
Locknut
Q’ty
1
1
1
1
1
16
