―３―
１４ １５～１９ ２０
１．
Blow off valve ×２
６．
Hose Clamp size #16 ×４
２．
Hose attachment ２９ φ ×２
７．
Blow off valve gasket ×２
３．
Rubber cap ３０ φ ×２
８．
Emblem ×２
４．
Vacuum hose ６ φ×３００㎜ ×２
９．
Bolt and washer ×４
５．
Power band ６ φ ×４
１ ２ ３ ４ ５
６ ７ ８ ９
Parts List Diagram
Parts List DiagramParts List Diagram
Parts List Diagram
Blow Off Valve Parts List
Blow Off Valve Parts ListBlow Off Valve Parts List
Blow Off Valve Parts List
