35
Floor Ceiling Type Fan
Coil Unit Service Manual
③.
Remove evaporator
Loosen the tapping screws on left side plate of
evaporator, cover and pipe clamp.
Cut off the wiring harness to remove the temp. sensor
on evaporator.
Remove the evaporator.
Left side plate T apping screw Cover
tapping screw water pipe clamp
Temp. sensor bushing
Temp. sensor wire Wiring harness
To Next Page
