Gree FP-34BA3/D-K

11
Wall Mounted Type
Fan Coil Unit Service Manual
PRODUCT
Model
FP-34BA2/D-K
FP-34BA3/D-K
FP-34BA4/D-K
FP-34BA5/D-K
FP-51BA2/D-K
FP-51BA3/D-K
FP-51BA4/D-K
FP-51BA5/D-K
FP-68BA2/D-K
FP-68BA3/D-K
FP-68BA4/D-K
FP-68BA5/D-K
FP-85BA2/D-K
FP-85BA3/D-K
FP-85BA4/D-K
FP-85BA5/D-K
Product Code
EM55001810
EM55002000
EM55002040
EM55002080
EM55001820
EM55002010
EM55002050
EM55002090
EM55001830
EM55002020
EM55002060
EM55002100
EM55001840
EM55002030
EM55002070
EM55002110
Air ow volume
High
m
3
/h 360 550 680 850
CFM 212 324 400 500
Medium
m
3
/h 322 413 591 708
CFM 189 242 347 416
Low
m
3
/h 282 367 532 616
CFM 166 215 312 362
Capacity
Cooling W 2000 2500 3600 4200
Heating W 2700 3200 4600 5400
Power system
Type V-Ph-Hz 220-240V~ 50Hz
Input W 50 50 60 66
Water system
Water ow volume
m
3
/h 0.4 0.45 0.6 0.7
GPM 1.76 1.98 2.65 3.09
Pressure drop
kPa 20 36 53 70
Ft·WG 7 12 17 23
Coil
Type Aluminum n-copper tube
Operating pressure MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa ≤1.6MPa
Motor
Type FN20J-PG FN20V-PG
Capacitor uF 1 1 1.5 1.5
Power output W 20
Sound pressure level dB(A) 35 40 43 48
Connection
pipe size
Water inlet &outlet inch 1/2"
Condensing
water drain
mm 15.6
Outline dimension (W×D×H) mm 845×180×275 940×200×298
Package dimension (W×D×H) mm 915×255×355 1010×285×380
Net weight kg 10 12
Gross weight kg 12.5 16
Loading quantity
20'GP 365 290
40'GP 765 595
40'HQ 850 671
Standard wireless remote controller YB1FA(XFAN)
Note:
(1) The water working temperature is from 7ºC(44.6ºF) to 60ºC(140ºF).
(2) The temperature exchange efficiency and enthalpy exchange efficiency are tested under these
testing conditions as below:
1) Cooling efciency: air 27ºC (80.6ºF) DB, 19ºC (66.2ºF) WB, water temperature in 7ºC (44.6ºF) water out
12ºC(53.6ºF).
2) Heating efciency: air 20ºC (68ºF) DB, water temperature in 50ºC (122ºF) , water out 40ºC (104ºF).
(3) The operating water pressure of the models above is no more than 1.6MPa.
