Gree FP-85BA3/D-K

33
Wall Mounted Type
Fan Coil Unit Service Manual
33
2 INSTALLATION DIMENSION DIAGRAM
Space to the ceiling
Space to the wall
Space to the wall
Air outlet side
Space to the floor
15cm
15cm
15cm
30cm
cm
300cm
50cm
Above
Above
Above
Above
Above
The dimensions of the space necessary for correct
installation of the appliance including the minimum
permissible distances to adjacent structures.
