Indoor side DB/WB(
℃
) Outdoor side DB/WB(
℃
)
Maximum cooling 32/23 43/26
Maximum heating 27/- 24/18
●
NOTICE:
The operating temperature range (outdoor temperature) for heat pump unit of
low-temperature cooling is
-15
℃
~ 43
℃.
For heat pump unit of low-temperature cooling and heating is
-22℃
~ 43
℃
.
Precautions
WARNING
Leak test is a must after installation.
It is not allowed to drill hole or burn the connection pipe.
The air conditioner must be installed in a room that is
larger than the minimum room area. The minimum room
area is shown on the nameplate or following table a.
The air conditioner is not allowed to use in a room that
has running fire (such as fire source, working coal gas
ware, operating heater).
Instructions for installation and use of this product are
provided by the manufacturer.
7
Working temperature range
