Gree GKH42K3FI

U-Match Series DC Inverter Service Manual
159
NO.
Name of Part
GFH09K3FI
Product Code
CF060N0420
Part Code
Quantity
1
Top Cover Board Assy
'01264176
1
2
Electric Box Cover
'01425200050
1
3
Left Side Plate Assy
'01315200072
1
4
Electric Box Assy
'01395200239
1
5
Main Board
'30224000030
1
6
Terminal Board
'42010194
1
7
Terminal Board
'4201025301
1
8
Left Evaporator Support
'01094122
1
9
Choke Plug of Drain Pipe
'76712455
1
10
Air intake side-board Sub-assy
'01494118
1
11
Water Tray Assy
01285200028
1
12
Evaporator Assy
01025200066
1
13
Lower Cover Plate Sub-Assy
01265200091
1
14
Right Support of Evaporator
'01094121
1
15
Supporter
'01804100140
1
16
Brushless DC Motor
'15704100001
1
17
Propeller Housing
'22202029
2
18
Right Side Plate Assy
'01314175
1
19
Hook
'02112446
4
20
Centrifugal fan
'10319051
2
21
Front Volute Casing
'22202030
2
22
side plate sub- assy of return air frame
'02225234
1
23
Filter
'11725202
1
24
Temperature Sensor
'390001921G
1
25
Ambient Temperature Sensor
'3900012123
1
26
Display Board
'30294000007
1
