GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
289
Parts List:
No.
Name of part
GMV-400WM/E-X
GMV-450WM/E1-X
Product Code
CN851W1820
Product Code
CN851W2210
Part code
Quantity
Part code
Quantity
1
Rear Grill
01574100002
2
01574100002
2
2
Top Cover
01264100006P
1
01264100006P
1
3
Diversion Circle
10474100002
2
10474100002
2
4
Motor for Axial Fan Assy
15404100018
2
15404100018
2
5
Axial Flow Fan Blade
10434100002
1
10434100002
1
6
Fan Motor
15704124
1
15704124
1
7
Gas By-pass Sub- Assy
04514100036
1
04514100036
1
8
Magnet Coil
4304000420
1
4304000420
1
9
Filter
07415200002
3
07415200002
3
10
Electromagnetic Valve
43000054
1
43000054
1
11
Cover Plate
01264100005P
1
01264100005P
1
12
Rear Grill
01574100001
01574100001
13
Condenser Assy
0112410009001
1
0112410009001
1
14
Low Pressure Survey
Valve Sub-Assy
07334100010
1
07334100010
1
15
Cut-off Valve 1/4
07130239
1
07130239
1
16
Throttle Assy
05374100003
1
05374100003
1
17
Electronic Expansion
Valve Fittingss
43044100012
1
43044100012
1
18
Electronic Expansion
Valve Fittings
4304413204
1
4304413204
1
19
Electronic Expansion
Valve
07331139
1
07331139
1
20
Discharge Valve
07334100002
2
07334100002
2
21
Electronic Expansion
Valve Fittings
4304413203
1
4304413203
1
22
Check Valve
04324001
2
04324001
2
23
Electronic Expansion
Valve
07334412
1
07334412
1
24
Bidirectional Filter
07210044
1
07210044
1
25
Plate-type Heat
Exchanger Sub-Assy
00904100007
1
00904100007
1
26
Dry Filter Sub-Assy
07314100002
1
07314100002
1
27
Gas Tube Filter
072190511
1
072190511
1
28
Dry Filter
07218769
1
07218769
1
29
Left Side Plate
01314712P
1
01314712P
1
30
Gas-liquid Separator
07424138
1
07424138
1
31
Oil Separator
0742418601
1
0742418601
1
32
Electrical
Heater(Compressor)
7651873209
1
7651873209
1
33
Chassis Sub-Assy
01194100001P
1
01194100001P
1
34
Base Frame Assy
01284100002
1
01284100002
1
35
Cut-off Valve 1/2
07334100013
1
07334100013
1
36
Liquid Valve Sub-Assy
07304100009
1
07304100009
1
37
Cut-off Valve 3/8
07334100011
1
07334100011
1
38
Valve
07304100007
1
07304100007
1
39
Cut-off Valve 1-1/8
07334100014
1
07334100014
1
40
Gas Valve Sub-Assy
07304100008
1
07304100008
1
41
Oil Equalizing Pipe
Sub-Assy 1
04224100054
1
04224100054
1
