GREE GMV5 INDOOR UNIT SERVICE MANUAL
24
Model
GMV-
ND22PLS/B1
-T
GMV-
ND25PLS/B1
-T
GMV-
ND28PLS/B1
-T
GMV-
ND32PLS/B1
-T
GMV-
ND36PLS/B1
-T
GMV-
ND40PLS/B1
-T
Heating capacity
kW
2.5
2.8
3.2
3.6
4.0
4.5
Air volume
m
3
/h
610
610
610
620
650
810
Unit external static pressure
Pa
10/30
10/30
10/30
10/30
10/30
10/30
Cooling power input
W
65
65
65
65
65
65
Cooling current input
A
0.30
0.30
0.30
0.30
0.30
0.30
Heating power input
W
65
65
65
65
65
65
Heating current input
A
0.30
0.30
0.30
0.30
0.30
0.30
*Minimum line current
A
0.63
0.63
0.63
0.63
0.63
0.63
*Maximum fuse current
A
1.1
1.1
1.1
1.1
1.1
1.1
Sound pressure level
dB(A)
38
38
38
38
38
37
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Φ6.35
Gas pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ12.7
Φ12.7
Φ12.7
Drain pipe
External diameter
×thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×D×H
mm
710×450
×200
710×450
×200
710×450
×200
710×450
×200
710×450
×200
1010×450
×200
Net weight
Main body
kg
19.0
19.0
19.0
20.0
20.0
24.0
Model
GMV-
ND45PLS/B1-T
GMV-
ND50PLS/B1-T
GMV-
ND56PLS/B1-T
GMV-
ND63PLS/B1-T
GMV-
ND71PLS/B1-T
Horse Power
HP
2
2
2
3
3
Cooling capacity
kW
4.5
5.0
5.6
6.3
7.1
Heating capacity
kW
5.0
5.6
6.3
7.0
8.0
Air volume
m
3
/h
810
810
810
810
1210
Unit external static pressure
Pa
10/30
10/30
10/30
10/30
10/30
Cooling power input
W
65
65
65
65
70
Cooling current input
A
0.30
0.30
0.30
0.30
0.32
Heating power input
W
65
65
65
65
70
Heating current input
A
0.30
0.30
0.30
0.30
0.32
*Minimum line current
A
0.63
0.63
0.63
0.63
0.63
*Maximum fuse current
A
1.1
1.1
1.1
1.1
1.1
Sound pressure level
dB(A)
37
37
37
37
39
Power supply
220-240V 1 phase ~50Hz/208-230V 1 phase ~60Hz
Piping
interface
Liquid pipe
mm
Φ6.35
Φ6.35
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ12.7
Φ12.7
Φ15.9
Φ15.9
Φ15.9
Drain pipe
External diameter
×thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Φ25×2.5
Dimensions
W×D×H
mm
1010×450×200
1010×450×200
1010×450×200
1010×450×200
1310×450×200
Net weight
Main body
kg
24.0
25.0
25.0
25.0
30.5
Notes:
① Rated cooling capacity test conditions: indoor 27°C DB/19°C WB, outdoor 35°C DB; connection
pipe length: 5 m, without height drop between units
② Rated heating capacity test conditions: indoor 20°C DB, outdoor 7°C DB/6 °C WB; connection
pipe length: 5 m, without height drop between units
③ In the column of “Unit external static pressure”: The figure before “/” indicates the default external
static pressure of unit before delivery, and the figures after indicate the adjustable static pressure
