Multi Variable Air Conditioners Cassette Type Indoor Unit
18
Fig 5.5
Note:
①
The type of indoor units must be the same if they are controlled by the same wired controller.
②
When the indoor unit is controlled by two wired controllers, the addresses of the two wired
controllers should be different through address setting. Address 1 is for main wired controller;
Address 2 is for slave wired controller. Detailed setting please refer to the owner’s manual of
wired controller.
