Gree GMV-ND28ZD/A-T

GREE GMV5 INDOOR UNIT SERVICE MANUAL
21
Model
GMV-
NX140P/A
(X1.2)-K
GMV-
NX224P/A
(X2.0) -M
GMV-
NX280P/A
(X2.5) -M
GMV-
NX280P/A
(X3.0) -M
GMV-
NX450P/A
(X4.0) -M
Maximum fuse current
A
3.7
4.7
5.4
5.5
7.6
Sound pressure level
dB(A)
42
47
48
51
58
Power supply
220-240V
1phase~50Hz
380-415V
3N~50Hz
380-415V
3N~50Hz
380-415V
3N~50Hz
380-415V
3N~50Hz
Piping
interface
Liquid pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Φ12.7
Gas pipe
mm
Φ15.9
Φ19.05
Φ22.2
Φ22.2
Φ28.6
Drain pipe
External diameter
×thickness
mm
Φ30×1.5
Φ30×1.5
Φ30×1.5
Φ30×1.5
Φ33×3.0
Dimensions
W×D×H
mm
1463×756
×300
1500×1000
×500
1500×1000
×500
1500×1000
×500
1700×1100
×650
Net weight
kg
63.5
130
134
134
208
Notes:
① Rated cooling capacity test conditions: fresh air inlet 35°C DB/28°C WB; connection pipe length:
5 m, without height drop between units; The default air outlet temperature of the unit is 18°C.
② Rated heating capacity test conditions: fresh air inlet 7°C DB/6°C WB; connection pipe length:
5 m, without height drop between units; The default air outlet temperature of the unit is 22°C.
DC Inverter Fresh Air Processing Indoor
Model
GMV-NDX125P/A-T
GMV-NDX140P/A-T
GMV-NDX224P/A-T
Horse Power
HP
5
5
8
Cooling capacity
kW
12.5
14.0
22.4
Heating capacity
kW*
1
8.5
10.0
16.0
kW*
2
10.5
12.0
20.0
Air volume
m
3
/h
1200/1000~2000
1200/1000~2000
2000/1500~3000
Static pressure (Pa)
Standard
150
150
200
Optional
50~200
50~200
50~300
Rated power input
W
350
350
760
Rated current input
A
2.0
2.0
4.3
Cooling power input
W
200
200
400
Cooling current input
A
1.5
1.5
2.5
Heating power input
W
200
200
400
Heating current input
A
1.5
1.5
2.5
Maximum fuse current
A
6
6
10
Sound pressure level
dB(A)
40~50
40~50
45~54
Power supply
220-240V 1 phase ~50Hz
208-230V 1 phase ~60Hz
Piping
diameter
Liquid pie
mm
Φ9.52
Φ9.52
Φ9.52
Gas pipe
mm
Φ15.9
Φ15.9
Φ19.05
Drain pipe
Outer diameter
×Wall thickness
mm
Φ25×2.5
Φ25×2.5
Φ25×2
Dimensions
W×D×H
mm
1400×700×300
1400×700×300
1483×791×385
Net weight
kg
54
54
82
Model
GMV-NDX250P/A-T
GMV-NDX280P/A-T
Horse Power
HP
10
10
Cooling capacity
kW
25.0
28.0
Heating capacity
kW*
1
18.0
20.0
kW*
2
20.0
22.0
