Reference of Debug Parameters of GMV5 DC Inverter Multi VRF System
No.
Debug item
Parameter name
Unit
Reference
driven bus voltage
voltage after rectification is: 220V X 1.414=311V. It’s
normal if actual voltage varies 15v from the calculated
voltage.
14
Operating freq of
inverter
compressor 2
Hz
Varies from 30Hz to 100Hz
15
Current of inverter
compressor 2
A
According to different operating freq. and different load,
current will vary from 7A to 25A.
16
IPM temp of
inverter
compressor 2
℃
(°F)
When ambient temp is lower than 35
℃
(95°F), IPM temp
is below 80
℃
(176°F). Highest temp won’t be above
95
℃
(203°F).
17
Inverter
compressor 2
driven bus voltage
V
Normal bus voltage is 1.414 times of power voltage. For
example, if 3-phase power voltage is 220V, then the bus
voltage after rectification is: 220V X 1.414=311V. It’s
normal if actual voltage varies 15v from the calculated
voltage.
18
System
parameters
ODU
Operating freq of
fan motor 1
Hz
Adjusts in 0~65Hz according to system pressure.
19
Current of fan
motor 1
A
20
Operating freq of
fan motor 2
Hz
Adjusts in 0~65Hz according to system pressure.
21
Current of fan
motor 2
A
22
IDU
Ambient temp of
IDU
℃
(°F)
——
23
Inlet tube temp of
indoor heat
exchanger
℃
(°F)
 According to different ambient temp, for a same IDU
under cooling mode, inlet tube temp will be 1~7
℃
(33.8~44.6°F) lower than outlet tube temp.
 For a same IDU under heating mode, inlet tube temp
will be 10~20
℃
(50~68°F) lower than outlet tube temp.
24
Outlet tube temp
of indoor heat
exchanger
℃
(°F)
25
Opening angle of
indoor EXV
PLS
Adjusts opening angle automatically in 200~2000PLS or
70~480PLS.
26
Communication
parameter
Communication data
—
Quantity of IDU and ODU detected by software is the
same with actual quantity. No communication error.
27
Drainage system
——
—
IDU can drain water out completely and smoothly.
Condensate pipe has no backward slope of water. Water
of ODU can be drained completely through drainage
pipe. No water drop from unit base.
28
Others
——
℃
(°F)
Compressor and indoor/outdoor fan motor has no
strange noise. Unit operates normally.
