REMOVING COLLECTED WATER
11
There are 2 ways to remove collected water:
1. Remove the rubber plug at drainage port.
2. Fix the drainage pipe clip on the right of rear side plate near drainage port with
a screw.
3. Put the drainage pipe into drainage port and screw it up, and then bind it with
pipe hoop.
4. Put the rubber plug into the other side of drainage pipe, fix it with pipe hoop and
then fix it in the drainage pipe clip.
Drainage port
Drainage pipe
clip
Drainage pipe
Pipe hoop
Drainage port
Screw
Rubber plug
Pipe hoop
Drainage
pipe clip
Use the continuous drainage option from the bottom hole.
Instructions for drainage pipe installation as follows.
Note: When using the continuous drainage option from the bottom hole, install
drainage pipe before using, otherwise poor drainage will affect normal
operation of the unit.
