Gree GPC10AH-A3NNC3B

5. Snap the free end of the drain hose into the drain hose clamp
Drain Hose
Install Exhaust Hose and Adapter
1. Roll air conditioner to its selected location. See “Location Requirements.”
2. Insert one end of the flexible exhaust hose into the exhaust adapter.
3. Twist clockwise to lock hose into place.
4. Insert the other end of the flexible exhaust hose into the window exhaust adapter.
5. Twist clockwise to lock hose into place.
A. Rubber plug
B. Drain port
C. Drain hose
D. Drain hose clip
E. Drain hose clamps
A. Exhaust adapter
B. Flexible exhaust hose
C. Window exhaust adapter
A
B
C
D
E
-
Drain Hose Clamp
A. Drain port
B. Attach drain hose clamp with screw provided.
A
B
- 12 -
DRAINAGE METHOD
A
B
C
