Gree GUD71P/A-T User Manual

DC Inverter U-match Series Duct Type Unit
6
2.2 Operating Range
Cooling Heating
Outdoor temperature DB(°C) -20~48 -20~24
Indoor temperature DB/WB(°C)(Maximum) 32/23 27/-
2.3 Standard Accessories
Indoor Unit Accessories
No. Name Appearance Q'ty Usage
1
Wired
Controller
1 To control the indoor unit.
2
Nut with
Washer
4
To fix the hook on the cabinet of
the unit.
3 Nut
4
To be used together with the
hanger bolt for installing the
unit.
4 Washer 4
To be used together with the
hanger bolt for installing the
unit.
5 Insulation
1 To insulate the gas pipe.
6 Insulation 1 To insulate the liquid pipe.
7 Fastener 8 To fasten the sponge.
8 Sponge 2 To insulate the drain pipe.
9 Sponge
1
To insulate the Fresh air inlet
(Only for GUD100-160PH/A-T
and GUD100-160PHS/A-T).
10
Removal-
Proof screw
Nut
1 To connect gas pipe.
11
Removal-
Proof screw
Nut
1 To connect liquid pipe.
Outdoor Unit Accessories
No. Name Appearance Q'ty Usage
1 Drain Plug 1 or 3 To plug the unused drain hole.
2
Drainage
Connector
or
1
To connect with the hard PVC
drain pipe.
