Gree GVH24AK-K3DNC8A

Service Manual
3
Technical Information
The above data is subject to change without notice; please refer to the nameplate of the unit.
Outdoor Unit
Model of Outdoor Unit GVH24AK-K3DNC8A/O
Product Code CH057W00100
Compressor Manufacturer/Trademark ZHUHAI LANDA COMPRESSOR CO., LTD.
Compressor Model QXFS-D25zX090H
Compressor Oil FW68DA
Compressor Type Rotary
Compressor RLA A 10.63
Compressor Power Input W 2366
Overload Protector HPC115/95U1
Throttling Method Electron expansion valve +Capillary
Operation Temp ºC 16~30
Ambient Temp (Cooling) ºC -15~43
Ambient Temp (Heating) ºC -20~24
Condenser Form Aluminum Fin-copper Tube
Pipe Diameter mm Φ7
Rows-n Gap mm 2-1.4
Coil Length (LXDXW) mm 980X790X427
Fan Motor Speed rpm 750
Output of Fan Motor W 60
Fan Motor RLA A 0.87
Fan Motor Capacitor μF /
Air Flow Volume of Outdoor Unit m
3
/h 4000
Fan Type Axial-ow
Fan Diameter mm Φ520
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating
Pressure for the Discharge Side
MPa 4.3
Permissible Excessive Operating
Pressure for the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 57/-/-
Sound Power Level (H/M/L) dB (A) 67/-/-
Dimension (WXHXD) mm 955X700X396
Dimension of Carton Box (LXWXH) mm 1026X455X735
Dimension of Package(LXWXH) mm 1029X458X750
Net Weight kg 54
Gross Weight kg 58
Refrigerant R410A
Refrigerant Charge kg 2.0
Connection
Pipe
Length m 5
Gas Additional Charge g/m 50
Outer Diameter Liquid Pipe mm Φ6
Outer Diameter Gas Pipe mm Φ16
Max Distance Height m 20
Max Distance Length m 30
Note: The connection pipe applies metric diameter.
