9
Technical Information
Service Manual
Model
4LIV12HP115V1A
Product Code
CB574001400
Power
Supply
Rated Voltage V~ 115
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 12000
Heating Capacity Btu/h 12000
Cooling Power Input W 1380
Heating Power Input W 1004
Cooling Current A 15
Heating Current A 10.9
Rated Input W 1650
Rated Current A 17.9
EER (Btu/h)/W 8.7
COP (Btu/h)/W 11.95
SEER 17.5(SEER) 17.5(SEER2)
HSPF 10(HSPF) 8.5(HSPF2)
Air Flow Volume CFM 424/353/324/277/247/224/182
Dehumidifying Volume Pint/d 2.96
Application Area yd
2
19-29
Indoor Unit
Indoor Unit Model
4LIV12HP115V1AH
Product Code of Indoor Unit
CB574N01400
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф94X630
Cooling Speed r/min
1550/1200/1120/1050/980/920/750/50
0
Heating Speed r/min 1450/1200/1140/1080/1020/960/900
Fan Motor Power Output W 15
Fan Motor RLA A 0.40
Fan Motor Capacitor μF /
Heater Power Input W /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5
Evaporator Row-n Gap mm 2-1.3
Evaporator Coil Length (LXDXW) mm 634X22.8X266.7
Swing Motor Model MP24HF
Swing Motor Power Output W 1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling:47/39/38/35/33/32/27/25
Heating:44/39/37/36/34/32/30
Sound Power Level dB (A)
Cooling:57/49/48/45/43/42/37/35
Heating:54/49/47/46/44/42/40
Dimension (WXHXD) inch 32 7/8X10 53/64X7 7/8
Package Carton Dimension (LXWXH) inch 35 3/64X12 61/64X10 15/64
Package Dimension (LXWXH) inch 35 15/64X13 37/64X10 43/64
Net Weight Ib 19.8
Gross Weight Ib 24.3
