Gree GWC09ATCXB-D3DNA1A/I User Manual

11
Technical Information
Service Manual
Model
4LIV18HP230V1A
Product Code
CB574003200
Power
Supply
Rated Voltage V~ 208/230
Rated Frequency Hz 60
Phases 1
Power Supply Mode Outdoor
Cooling Capacity Btu/h 17600
Heating Capacity Btu/h 19100
Cooling Power Input W 1750
Heating Power Input W 1750
Cooling Current A 7.95
Heating Current A 7.95
Rated Input W 2300
Rated Current A 9.5
EER (Btu/h)/W 10.05
COP (Btu/h)/W 10.90
SEER 17.5(SEER) 17.5
(
SEER2)
HSPF 9(HSPF) 8.5(HSPF2)
Air Flow Volume CFM 618/512/471/436/395/336/283
Dehumidifying Volume Pint/d 3.8
Application Area yd
2
28-41
Indoor Unit
Indoor Unit Model
4LIV18HP230V1AH
Product Code of Indoor Unit
CB574N03200
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Ф106X706
Cooling Speed r/min 1350/1200/1120/1050/980/860/750
Heating Speed r/min 1350/1200/1120/1050/950/850/750
Fan Motor Power Output W 45
Fan Motor RLA A 0.7
Fan Motor Capacitor μF /
Heater Power Input W /
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5
Evaporator Row-n Gap mm 2-1.2
Evaporator Coil Length (LXDXW) mm 700X22.8X381
Swing Motor Model MP35CJ
Swing Motor Power Output W 2.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling:50/46/44/42/40/36/32
Heating:49/46/44/41/38/34/30
Sound Power Level dB (A)
Cooling:60/56/54/52/50/46/42
Heating:59/56/54/51/48/44/40
Dimension (WXHXD) inch 37 1/8X13 7/64X9 11/16
Package Carton Dimension (LXWXH) inch 39 7/32X15 5/8X12 9/32
Package Dimension (LXWXH) inch 39 13/32X15 15/16X12 43/64
Net Weight Ib 28.7
Gross Weight Ib 34.2

Gree GWC09ATCXB-D3DNA1A/I Specifications

General

Brand	Gree
Model	GWC09ATCXB-D3DNA1A/I
Category	Air Conditioner
Language	English
