97
Removal Procedure
Provide a protective sheet or
a steel plate so that the
brazing flame cannot
influence peripheries.
CautionCaution
CautionCaution
Caution
Be careful about the four way
valve, pipes and so on, which
were heated up by a gas
brazing machine, so as not
to get burnt your hands.
2
3
4-way Valve
Unsolder the weld spot
bet
ween the four-way
valve and compressor,
valve and then remove the
four-way valve sub-assy.
Twist off the three foot nuts
on compressor and then
remove the compressor.
To Next Page
