Exploded Views and Parts list
8.2 Parts List
Indoor Unit
(1) 18K
GWC18KG-K3DNA5A/I GWH18KG-K3DNA5A/I GWH18KG-K3DNA5B/I
Product Code CB146N0090 CB146N0100 CB146N0320
1 Front Panel Assy 20012496 20012496 20012496 1
2 Filter Sub-Assy 11122104 11122104 11122104 2
3 Screw Cover 242520041 242520041 242520041 1
4 Front Case Assy 20012497 20012497 20012497 1
5 Guide Louver 10512140 10512140 10512140 1
6 Air Louver 10512160 10512160 10512160 2
7 Helicoid tongue 26112232 26112232 26112232 1
8 Left Axile Bush 10512037 10512037 10512037 1
9 Rear Case assy 22202154 22202154 22202154 1
10 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
11 O-Gasket sub-assy of Bearing 76512051 76512051 76512051 1
12 O-Gasket of Cross Fan Bearing 76512203 76512203 76512203 1
13 Evaporator Support 24212119 24212119 24212119 1
14 Evaporator Assy 01002600 01002600 01002603 1
15 Wall Mounting Frame 01252484 01252484 01252484 1
16 Cross Flow Fan 10352036 10352036 10352036 1
17 Motor Press Plate 26112231 26112231 26112231 1
18 Fan Motor 15012116 15012116 15012116 1
19 Pipe Clamp 26112164 26112164 26112164 1
20 Drainage hose 0523001407 0523001407 0523001407 1
21 Step Motor 15012086 15012086 15012086 1
22 Crank 10582070 10582070 10582070 1
23 Electric Box Assy 20202390 20202291 20202404 1
24 Electric Box 20112103 20112103 20112103 1
25 Axile Bush 10542008 10542008 10542008 1
26 Indicator Light Cover 22242084 22242084 22242084 1
27 Indicator shield cover 22242083 22242083 22242083 1
28 Terminal Board 4201026601 4201026601 4201026601 1
29 Jumper 4202300117 4202300117 4202300122 1
30 Electric Box Cover2 20112081 20112081 20112081 1
31 Main Board 30138506 30138505 30138505 1
32 Display Board 30568112 30568112 30568112 1
33 Shield Cover of Electric box Cover 01592088 01592088 01592088 1
34 Electric Box Cover 20122123 20122123 20122123 1
35 Shield cover of Electric Box 01592087 01592087 01592087 1
36 Power Cord 400204873 400204873 400204873 1
37 Connecting Cable 400205382 400205382 400205382 1
38 Remote Controller 30510061 30510061 30510061 1
No
Description
Qty
Part Code
To Next Page
