50
Exploded Views and Parts list
GWC24KG-K3DNA6A/I GWH24KG-K3DNA6A/I GWH24KG-K3DNA6B/I
Product Code CB146N0640 CB146N0260 CB146N0600
1 Front Panel Assy 20012502S 20012502S 20012502S 1
2 Filter Sub-Assy 11122091 11122091 11122091 2
3 Screw Cover 24252016 24252016 24252016 3
4 Front Case Assy 20012514 20012514 20012514 1
5 Air Louver 10512139 10512139 10512139 3
6 Helicoid tongue 26112229 26112229 26112229 1
7 Left Axile Bush 10512037 10512037 10512037 1
8 Rear Case assy 22202157 22202157 22202157 1
9 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
10 Ring of Bearing 26152025 26152025 26152025 1
11 O-Gasket of Cross Fan Bearing 76512203 76512203 76512203 1
12 Cross Flow Fan 10352030 10352030 10352030 1
13 Evaporator Support 24212103 24212103 24212103 1
14 Evaporator Assy 01002269 01002269 01002269 1
15 Wall Mounting Frame 01252004 01252004 01252004 1
16 Motor Press Plate 26112184 26112184 26112184 1
17 Fan Motor 15012098 15012098 15012098 1
18 Pipe Clamp 26112188 26112188 26112188 1
19 Drainage hose 0523001405 0523001405 0523001405 1
20 Step Motor 1521300101 1521300101 1521300101 1
21 Crank 10582070 10582070 10582070 1
22 Guide Louver 10512138 10512138 10512138 1
23 Axile Bush 10542008 10542008 10542008 2
24 Electric Box 20112103 20112103 20112103 1
25 Terminal Board 4201026601 4201026601 4201026601 1
26 Main Board 30138514 30138513 30138513 1
27 Electric Box Cover2 20112081 20112081 20112081 1
28 Shield Cover of Electric box Cover 01592088 01592088 01592088 1
29 Electric Box Cover 20122123 20122123 20122123 1
30 Indicator shield cover 22242083 22242083 22242083 1
31 Indicator Light Cover 22242084 22242084 22242084 1
32 Display Board 30568112 30568112 30568112 1
33 Shield cover of Electric Box 01592087 01592087 01592087 1
34 Electric Box Assy 2020230201 20202302 2020230204 1
35 Power Cord 400203253 400203253 400203253 1
36 Connecting Cable 400205382 400205382 400205382 1
37 Remote Controller 30510061 30510061 30510061 1
No
Description
Qty
Part Code
To Next Page
