Gree GWC18KG-K3DNA6A

53
Exploded Views and Parts list
GWH18KG-K3DNA5A/O GWH18KG-K3DNA5B/O
Product Code CB146W0100 CB146W0320
1 Fan Motor 1501506301 1501506301 1
2 Electric box (fireproofing) 01413148 01413148 1
3 Terminal Board 42011113 42011113 1
4 Capacitor CBB61 33010010 33010010 1
5 Electric Box 20113008 20113008 1
6 Radiator 49010252 49010252 1
7 Main Board 30138333 30138568 1
8 Electric Box Cover Sub-Assy 02603217 02603217 1
9 Electric Box Assy 02603272 02603337 1
10 left handle 26235401 26235401 1
11 Left Side Plate 01305041P 01305041P 1
12 Motor Support Sub-Assy 01705020 01705020 1
13 Supporting board(condenser) 01795010 01795010 1
14 Top Cover 01255005P 01255005P 1
15 Reactor 43130021 43130021 1
16 Clapboard Sub-Assy 01232902 01232902 1
17 Condenser Assy 01113530 01113635 1
18 Rear Grill 01473043 01473043 1
19 Wiring clamp 26115004 26115004 1
20 Temperature Sensor 3900030901 3900030901 1
21 Capacitor CBB65 33000065 33000065 1
22 Capacitor Clamp sub-assy 01413098 01413098 1
23 Handle 26235254 26235254 1
24 Cut-off valve Sub-Assy 07133204 07133204 1
25 Cut-off valve Sub-Assy 07133060 07133060 1
26 Valve support assy 01715010P 01715010P 1
27 Right Side Plate 01305053P 01305053P 1
28 Capillary Sub-Assy 03063077 03063168 1
29 4-way Valve Assy 0312324501 0312324501 1
30 Magnet Coil 4300040033 4300040033 1
31 Compressor and fittings 00103501 00103501 1
32 Chassis Sub-assy 0120371401P 0120371401P 1
33 Drainage Connecter 06123401 06123401 1
34 Drainage Plug 06813401 06813401 3
35 Axial Flow Fan 10335008 10335008 1
36
Insulated board (cover of electric
box)
20113003 20113003 1
37 Front Panel 01535008P 01535008P 1
38 Front grill 22415002 22415002 1
No
Description
Qty
Part Code
(2) 18K Heat Pump
