Gree GWC18KG-K3DNA6A

90
Removal Procedure
7. Remove electrical box
Disconnect the Cable
clamp
1
Remove Temperature
Sensor; Disconnect the
connection wires.
2
Pay attention to the direction
of the retainer of the
thermistor so that the
retainer will not touch the
harness (same as the
existing models.)
Terminal
board
Connecting
wires
Heat exchanger thermistor
Remove a screw on the
electrical box.
3
Twist off the earthing screw
fixing the evaporator;
Pull out the all the wiring
terminals
