NO.
Description
Part Code
QtyGWC30LB-D3DNB2G/I GWH30LB-D3DNB2G/I
Product Code CB433N00102 CB433N00202
1 Receiver Window / / /
2 Front Panel 20000300022S 20000300022S 1
3 Stand bar 2421212001 2421212001 1
4 Filter Sub-Assy 11122106 11122106 2
5 Front Case Sub-Assy 20900700005 20900700005 1
6 Upper Guide Louver 1051216601 1051216601 1
7 Lower guide louver 1051216701 1051216701 1
8 Axile Bush 10542704 10542704 6
9 Air Louver 2 1051216902 1051216902 2
10 Air Louver 1 1051216802 1051216802 16
11 Connecting Rod 10582086 10582086 2
12 Louver Clamp 26112158 26112158 9
13 Water Tray 2018213802 2018213802 1
14 Screw Cover 2425200506 2425200506 4
15 Rubber Plug (Water Tray) 76712012 76712012 1
16 Rear Case Sub-Assy 00000100113 00000100113 1
17 Cross Flow Fan 1 10352039 10352039 1
18 Bearing Holder sub-assy 26152028 26152028 1
19 Cross Flow Fan 2 10352040 10352040 1
20 O-Gasket sub-assy of Bearing 76512051 76512051 1
21 Left Evaporator Support 24212041 24212041 1
22 Evaporator Assy 01002000027 01002000027 1
23 Wall Mounting Frame 01252398 01252398 1
24 Right Support of Evaporator 2421204201 2421204201 1
25 Fan Motor 1501213401 1501213401 1
26 Pipe Clamp 26112071 26112071 1
27 Drainage hose 0523001404 0523001404 1
28 Fixed Clip (Evaporator) 02112009 02112009 1
29 Cover Plate 2012212402 2012212402 1
30 Motor Fixed Clip 26112324 26112324 1
31 Step Motor 1521210701 1521210701 1
32 Press plate (crank) 26112070 26112070 1
33 Crank-guide 10582041 10582041 1
34 Upper Crank 10562004 10562004 1
35 Lower crank 10562005 10562005 1
36 Electric Box Assy 10000203983 10000204113 1
37 Electric Box 201022502 201022502 1
38 Terminal Board 42011233 42011233 1
39 Main Board 30138001022 30138001017 1
40 Display Board 30565277 30565277 1
41 Electric Box Cover 2011204404S 2011204404S 1
42 Electric Box Cover 201022523 201022523 1
43 Remote Controller 305001000085 305001000085 1
44 Tube Sensor 390000592 390000592 1
45 Ambient Temperature Sensor 390000453 390000453 1
46 Detecting plate(WIFI) 30070077 30070077 1
To Next Page
