Installation and Maintenance
Service Manual
Step Procedure
4. Remove grille
Remove the screws fixing the grille and then remove
the panel grille.
5. Remove front panel
Remove screws xing the front panel and then remove
the front panel.
6. Remove right side plate
Remove screws xing connecting the front panel with
the chassis and the motor support, and then remove
the right side plate.
grille
screws
front panel
screws
screws
right side plate
screws
screws
To Next Page
