Gree GWH09AFC-K6DNA2F/O

90
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
Drainage pipe
Space to the obstruction
At least 50cm
At least 15cm
A
At least 250cm
Spac e ceiling
Space to the wall
e to th
t least 15cm
At least 15cm
Space to the wall
At least 300cm
Space to the obstruction
Space to the floor
Space to the obstruction
200cm
At least
obstru
Space to the
At lea
ction
st 50cm
t least 30cm
Space to the wall
A
Space to the obstruction
At least 30cm
