15
Technical Information
Service Manual
Model
1.GWH12QC-K6DNA5F 2.GWH12QC-K6DNB2F
3.GWH12QC-K6DND2F
Product Code
1.CB425016200 2.CB432026102
3.CB461007502
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 3510
Heating Capacity W 3810
Cooling Power Input W 962
Heating Power Input W 953
Cooling Current Input A 4.3
Heating Current Input A 4.6
Rated Input W 1550
Rated Cooling Current A 6.2
Rated Heating Current A 6.9
Air Flow Volume m
3
/h 700/650/600/540/480/420/360
Dehumidifying Volume L/h 1.40
EER W/W 3.65
COP W/W 4.00
SEER -- 7.1
SCOP (Warmer/Average/Colder) -- 5.2/4.1/3.1
Application Area m
2
16-24
Indoor Unit
Model
1.GWH12QC-K6DNA5F/I 2.GWH12QC-K6DNB2F/I
3.GWH12QC-K6DND2F/I
Product Code
1.CB425N16200 2.GWH12QC-K6DNB2F/I
3.CB461N07502
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ98X633.5
Cooling Speed r/min 1350/1200/1100/1000/920/850/800
Heating Speed r/min 1300/1200/1120/1050/980/900/850
Fan Motor Power Output W 20
Fan Motor RLA A 0.31
Fan Motor Capacitor μF 1.5
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 635X22.8X306.3
Swing Motor Model MP24EB/MP24HF
Swing Motor Power Output W 1.5/1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling:42/38/35/32/29/26/25
Heating:42/38/36/34/32/30/28
Sound Power Level dB (A)
Cooling:57/50/47/44/41/38/37
Heating:52/48/46/44/42/40/38
Dimension (WXHXD) mm 845X289X209
Dimension of Carton Box (LXWXH) mm 900X351X272
Dimension of Package (LXWXH) mm 905X367X283
Net Weight kg 11
Gross Weight kg 13
