Technical Information
Service Manual
Model
1.GWH12QB-K6DNB2A 2.GWH12QB-K6DNB4A
3.GWH12QB-K6DNB8A 4.GWH12QB-K6DNC4A
Product Code
1.CB432025502/CB432025503 2.CB434020501
3.CB438012700 4.CB444013900
Power
Supply
Rated Voltage V~
220-240
Rated Frequency Hz
50
Phases
1
Power Supply Mode
Outdoor
Cooling Capacity W
3200
Heating Capacity W
3400
Cooling Power Input W
991
Heating Power Input W
916
Cooling Current Input A
4.4
Heating Current Input A
4
Rated Input W
1500
Rated Cooling Current A
6
Rated Heating Current A
7.5
Air Flow Volume m
3
/h
590/480/410/280
Dehumidifying Volume L/h
1.4
EER W/W
3.23
COP W/W
3.71
SEER
-- 6.1
SCOP (Warmer/Average/Colder)
-- 4.9/4.0/-
Application Area m
2
15-22
Indoor Unit
Model
1.GWH12QB-K6DNB2A/I 2.GWH12QB-K6DNB4A/I
3.GWH12QB-K6DNB8A/I 4.GWH12QB-K6DNC4A/I
Product Code
1.CB432N25502/CB432N25503 2.CB434N20501
3.CB438N12700 4.CB444N13900
Fan Type
Cross-ow
Fan Diameter Length(DXL) mm
Ф98X580
Cooling Speed r/min
1350/1200/1050/750
Heating Speed r/min
1350/1200/1050/850
Fan Motor Power Output W
20
Fan Motor RLA A
0.22
Fan Motor Capacitor μF
1
Evaporator Form
Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm
Φ5
Evaporator Row-n Gap mm
2-1.4
Evaporator Coil Length (LXDXW) mm
584X22.8X266.7
Swing Motor Model
MP24AA
Swing Motor Power Output W
1.5
Fuse Current A
3.15
Sound Pressure Level dB (A)
Cooling:41/37/33/24
Heating:42/38/33/27
Sound Power Level dB (A)
Cooling:57/50/45/34
Heating:53/51/46/39
Dimension (WXHXD) mm
790X275X200
Dimension of Carton Box (LXWXH) mm
850X339X262
Dimension of Package (LXWXH) mm
852X355X273
Net Weight kg
9
Gross Weight kg
11
