NO. Description
1
Front Panel
2 Display Board
3
Front Case Assy
4
Helicoid Tongue
5 Left Axile Bush
6 Rear Case assy
7 Drainage Hose
8
Ring of Bearing
9 O-Gasket sub-assy of Bearing
10 Evaporator Support
11 Evaporator Assy
12 Wall Mounting Frame
13
Fan Motor
14 Cross Flow Fan
15
Connecting pipe clamp
16 Rubber Plug (Water Tray)
17 Stepping Motor
18 Crank
19 Electric Box Assy
20 Axile Bush
21 Terminal Board
22
Jumper
23
Main Board
24 Electric Box Cover Sub-Assy
25 Shield Cover of Electric Box Cover
26 Electric Box Cover
27 Remote Controller
28 Detecting Plate
Some models may not contain some parts, please refer to the actual product.
