11
Technical Information
Service Manual
Model
1.GWH09QC-K6DNB2F 2.GWH09QC-K6DNC4F
3.GWH09QC-K6DND2F
Product Code
1.CB432026000 2.CB444013400
3.CB461007700
Power
Supply
Rated Voltage V~ 220-240
Rated Frequency Hz 50
Phases 1
Power Supply Mode Outdoor
Cooling Capacity W 2700
Heating Capacity W 3000
Cooling Power Input W 695
Heating Power Input W 700
Cooling Current Input A 3.1
Heating Current Input A 3.2
Rated Input W 1400
Rated Cooling Current A 6
Rated Heating Current A 6.2
Air Flow Volume m
3
/h 610/570/540/470/440/420/390
Dehumidifying Volume L/h 1.69
EER W/W 3.88
COP W/W 4.29
SEER -- 7.5
SCOP (Warmer/Average/Colder) -- 5.3/4.2/3.4
Application Area m
2
12-18
Indoor Unit
Model
1.GWH09QC-K6DNB2F/I 2.GWH09QC-K6DNC4F/I
3.GWH09QC-K6DND2F/I
Product Code
1.CB432N26000 2.CB444N13400
3.CB461N07700
Fan Type Cross-ow
Fan Diameter Length(DXL) mm Φ98X633.5
Cooling Speed r/min 1200/1100/1050/950/900/850/800
Heating Speed r/min 1150/1100/1050/1000/950/900/850
Fan Motor Power Output W 20
Fan Motor RLA A 0.31
Fan Motor Capacitor μF 1.5
Evaporator Form Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Φ5
Evaporator Row-n Gap mm 2-1.4
Evaporator Coil Length (LXDXW) mm 635X22.8X306.3
Swing Motor Model MP24EB/MP24HF
Swing Motor Power Output W 1.5/1.5
Fuse Current A 3.15
Sound Pressure Level dB (A)
Cooling:38/36/34/31/29/27/25
Heating:38/37/35/34/32/29/28
Sound Power Level dB (A)
Cooling:54/48/46/43/41/39/37
Heating:56/49/47/46/44/41/40
Dimension (WXHXD) mm 845X289X209
Dimension of Carton Box (LXWXH) mm 918X278/364
Dimension of Package (LXWXH) mm 931X281X379
Net Weight kg 10.5
Gross Weight kg 12.5
