134
Installation and Maintenance
Service Manual
NO. Description
1 Coping
2 4-Way Valve Assy
3 Handle (Right)
4 Sponge(Condenser)
5 Temperature Sensor Support
6 Condenser Assy
7
Capillary Sub-assy/
Electric Expansion Valve Sub-Assy
8 Sensor Insert
9 Right Side Plate
10 Earthing Plate Sub-Assy
11 Wire Clamp
12 Valve Cover
13 Silencer
14 Cut off Valve Sub-Assy
15 Strainer
16 Valve Support
17 Compressor and Fittings
18 Chassis Sub-assy
19 Motor Support
20 Fan Motor
21 Axial Flow Fan
22 Cabinet
23 Front Grill
24 Drainage Joint(ODU)
25 Left Side Plate
26 Clapboard
27 Electric Box Assy
28 Electric Box
29 Main Board
30 Electric Box Cover
31 Terminal Board
32 Temperature Sensor
33 Raidator
Some models may not contain some parts, please refer to the actual product.
