14
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model GWH12AFC-K6DNA2F/O(LC)
Outdoor Unit Product Code CB363W03601
Compressor Manufacturer ZHUHAI LANDA COMPRESSOR CO.,LTD
Compressor Model FTz-AN108ACBD
Compressor Oil FW68DA or equivalent
Compressor Type Rotary
Compressor LRA. A /
Compressor RLA A 4.40
Compressor Power Input W /
Compressor Overload Protector /
Throttling Method
Electron expansion valve
Set Temperature Range ºC
16~30
Cooling Operation Ambient Temperature Range ºC -15~50
Heating Operation Ambient Temperature Range ºC
-15~30
Condenser Form
Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Φ7.94
Condenser Rows-n Gap mm 1-1.2
Condenser Coil Length (LXDXW) mm 666X19.05X527
Fan Motor Speed rpm 900
Fan Motor Power Output W 30
Fan Motor RLA A 0.40
Fan Motor Capacitor μF
/
Heater Power Input W
/
Outdoor Unit Air Flow Volume m
3
/h 1950
Fan Type Axial-ow
Fan Diameter mm Φ400
Defrosting Method Automatic Defrosting
Climate Type T1
Isolation I
Moisture Protection IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5
Sound Pressure Level (H/M/L) dB (A) 52/-/-
Sound Power Level (H/M/L) dB (A) 63/-/-
Dimension(WXHXD) mm 732X555X330
Dimension of Carton Box (LXWXH) mm 791X373X583
Dimension of Package(LXWXH) mm 794X376X598
Net Weight kg 24.5
Gross Weight kg 27
Refrigerant
R32
Refrigerant Charge kg 0.57
Connection
Pipe
Connection Pipe Length m 5
Connection Pipe Gas Additional Charge g/m
16
Outer Diameter Liquid Pipe inch 1/4
Outer Diameter Gas Pipe inch 3/8
Max Distance Height m
10
Max Distance Length m 15
Note: The connection pipe applies metric diameter.
