58
Technical Information
Service Manual
1
2
3
4
56
7
8
No. Name
1
Neutral wire, live wire and
communication cable
2 4-way valve
3
electric heating belt of
chasssis
4 Electronic expansion valve
5 Outdoor fan
6 Temperature sensor
7 Overload
8 Three-phase terminal of compressor
GWH24ALD-K6DNA1B/O
