Gree GWH09QA-K6DNB4A/I

62
Technical Information
Service Manual
button
● Press this button, can select Sleep 1 ( ), Sleep 2 ( ), Sleep
3 ( ) and cancel the Sleep, circulate between these, after
electried, Sleep Cancel is defaulted. Sleep 1 is Sleep mode 1,
in Cool modes; sleep status after run for one hour, the main unit
setting temperature will increase 1 , two hours, setting temperature
increased 2 , then the unit will run at this setting temperature;
In Heat mode: sleep status after run for one hour, the setting
temperature will decrease 1 , two hours, setting temperature will
decrease 2 , then the unit will run at this setting temperature.
● Sleep 2 is sleep mode 2, that is air conditioner will run according
to the presetting a group of sleep temperature curve.
● Sleep 3-the sleep curve setting under Sleep mode by DIY;
(1) Under Sleep 3 mode, press “Turbo” button for a long time,
remote controller enters into user individuation sleep setting
status, at this time, the time of remote controller will display “1hour”,
the setting temperature “88” will display the corresponding
temperature of last setting sleep curve and blink (The rst entering
will display according to the initial curve setting value of original
factory);
(2) Adjust "▲" a nd " ▼" button, could change the corresponding
setting temperature, after adjusted, press “Turbo” button for
conrmation;
(3) At this time, 1hour will be automatically increased at the timer
position on the remote control, (that are "2hours" or "3hours" or "8
hours " ), the place of setting temperature " 88 " will display the
corresponding temperature of last setting sleep curve and blink;
(4) Repeat the above step (2)~(3) operation, until 8 h ours tempe
rature setting  nished, sleep,curve setting nished, at this time,
the remote controller will resume the original timer display;
temperature display will resume to original setting temperature.
● Sleep 3-the sleep curve setting under Sleep mode by DIY could
be inquired: The user could accord to sleep curve setting method
to inquire the presetting sleep curve, enter into user individuation
sleep setting status, but do not change the temperature, press
“Turbo” button directly for confirmation. Note: In the above
presetting or enquiry procedure, if continuously within 10s, there
is no button pressed, the sleep curve setting within 10s, there
is no button pressed , the sleep cu rve setting status will be
automatically quit and resume to display the original displaying.
In the presetting or enquiry procedure, press "ON/OFF" button,
"Mode" button, " Sleep " butto n, the sleep curve setting or enquiry
status will quit similarly.
button
Press this button to start I FEEL function and " " will be
displayed on the remote controller. After this function is set, the
remote controller will send the detected ambient temperature
to the controller and the unit will automatically adjust the indoor
temperature according to the detected temperature. Press this
button again to close I FEEL function and " " will disappear.
Please put the remote controller near user when this function
is set. Do not put the remote controller near the object of high
temperature or low temperature in order to avoid detecting
inaccurate ambient temperature. When I FEEL function is turned
on, the remote controller should be put within the area where
indoor unit can receive the signal sent by the remote controller.
button
● TIMER ON button
"TIMER ON" button can set th e time for timer on. After pressing
this button, " " icon disappears and the word "ON" on remote
controller blinks. Press "▲" or "▼" button to adjust TIMER ON
setting. After each pressing "▲" or "▼" button. TIMER ON setting
will increase or decrease 1min. Holding "▲" or "▼" button, 2s
later, the time will change quickly until reaching your required time.
Press "TIMER ON" to conrm it. The word "ON" will stop blinking.
" " icon resumes displaying. Cancel TIMER ON: Under the
condition that TIMER ON is started up, press "TIMER ON" button
to cancel it.
● TIMER OFF button
"TIMER OFF" button can set the time for timer off. After pressing
this button, " " icon disappears and the word "OFF" on remote
controller blinks. Press "▲" or "▼" button to adjust TIMER OFF
setting. After each pressing "▲" or "▼" button, TIMER OFF
setting will increase or decrease 1min. Holding "▲" or "▼" button,
2s later, the time will change quickly until reaching your required
time. Press "TIMER OFF" and the word "OFF" will stop blinking.
" " icon resumes displaying. Under the condition that TIMER
OFF is started up, press "TIMER OFF" button to cancel it.
NOTE:
● Under on and off status, you can set TIMER OFF or TIMER ON
simultaneously.
● Before setting TIMER ON or TIMER OFF, please adjust the
clock time.
● When turning on TIMER ON or TIMER OFF function, set this
function valid all the time and the air conditioner will be turned on
or turned off at set temperature every day. " " button has no
affect to setting. If this function is not required, use the remote
controller to cancel it.
button
Press this button to set clock time. " " icon on remote controller
will blink. Press "▲" or "▼" button within 5s to set clock time.
Each pressing of "▲" or "▼" button, clock time will increase or
decrease 1 minute. If hold "▲" or "▼" button, 2s later, time will
change quickly. Release this button when reaching your required
time. Press "CLOCK" button to conrm the time. " " icon stops
blinking.
NOTE:
● Clock time adopts 24-hour mode.
● The interval between two operations can't exceed 5s.
Otherwise, remote controller will quit setting status.
Operation for TIMER ON/TIMER OFF is the same.
