168
Installation and Maintenance
Service Manual
Step Procedure
7. Remove electric box assy
Remove the screws fixing the electricbox; loosen the
wire bundle; pull out the wiring terminals and then pull
electric boxupwards to remove it.
8. Remove axial ow blade
Remove nut fixing the blade and then remove the
blade.
9. Remove motor
Remove screws xing the motor and then remove the
motor.
screws
electric box
assy
axial ow
blade
nut
screws
motor
To Next Page
