Gree GWH12AGB-K6DNA1A/O

8
Technical Information
Service Manual
Model
GWH09QB-K6DNE4E
GWH09QB-K6DNA5E
1.GWH09QB-K6DNA1E
2.GWH09QB-K6DNA5E
3.GWH09QB-K6DNB6E
4.GWH09QB-K6DNC2E
5.GWH09QB-K6DNB2E
6.GWH09QB-K6DNC6E
7.GWH09QB-K6DNE4E
8.GWH09QB-K6DNB4E
9.GWH09QB-K6DNB8E
10.GWH09QB-K6DND6E
11.GWH09QB-K6DND2E
Product Code
CB470002702
CB425012502
1.CB419015800 2.CB425012500
3.CB435009600 4.CB439013300
5.CB432017600/CB432017602
6.CB443006002
7.CB470002700 8.CB434012300
9.CB438010100 10.CB460005900
11.
（
CB461005800/CB461005802
/CB461005801
）
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2700 2700
Heating Capacity W 2800 2800
Cooling Power Input W 820 820
Heating Power Input W 755 755
Cooling Current Input A 3.8 3.8
Heating Current Input A 3.5 3.5
Rated Input W 1500 1500
Rated Current A 3.8 3.8
Air Flow Volume(SS/H/MH/M/ML/L/SL) m
3
/h 560/490/460/430/380/330/290 560/490/460/430/380/330/290
Dehumidifying Volume L/h 0.8 0.8
EER W/W 3.29 3.29
COP W/W 3.71 3.71
SEER 6.8 6.8
SCOP(Average/Warmer/Colder) 4/5.1/3.2 4/5.1/3.2
Application Area m
2
12-18 12-18
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф98X580 Ф98X580
Cooling Speed(SS/H/MH/M/ML/L/SL) r/min 1350/1200/1120/1050/920/800/750 1350/1200/1120/1050/920/800/750
Heating Speed(SS/H/MH/M/ML/L/SL) r/min 1300/1200/1120/1050/950/850/800 1300/1200/1120/1050/950/850/800
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.215 0.215
Fan Motor Capacitor μF 1 1
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Ф5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length(LXDXW) mm 584X22.8X266.7 584X22.8X266.7
Swing Motor Model MP24AA MP24AA/MP24HF
Swing Motor Power Output W 1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level(SS/H/MH/M/ML/L/SL) dB (A) 41/37/35/32/29/26/24 41/37/35/32/29/26/24
Sound Power Level(SS/H/MH/M/ML/L/SL) dB (A) 55/48/46/44/40/37/35 55/48/46/44/40/37/35
Dimension(WXHXD) mm 790X275X200 790X275X200
Dimension of Carton Box(LXWXH) mm 863X268X352 863X268X352
Dimension of Package(LXWXH) mm 866X271X367 866X271X367
Net Weight kg 9 9
Gross Weight kg 11 11
