Technical Information
Service Manual
Model
GWH09QC-K6DNC2A
GWH09QC-K6DND2A
GWH12QC-K6DNC2A
GWH12QC-K6DND2A
Product Code
CB439014100
CB461006600
CB439014200
CB461006500
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Outdoor Outdoor
Cooling Capacity W 2700 3500
Heating Capacity W 2930 3810
Cooling Power Input W 585 950
Heating Power Input W 650 975
Cooling Current Input A 2.6 4.0
Heating Current Input A 2.9 4.5
Rated Input W 1650 1650
Rated Current A 6.4 6.4
Air Flow Volume(SH/H/MH/M/ML/L/SL) m
3
/h 560/490/460/430/380/330/290 680/590/540/490/450/420/390
Dehumidifying Volume L/h 0.8 1.4
EER W/W 4.62 3.68
COP W/W 4.51 3.91
SEER W/W 8.5 8.5
SCOP(Average/Warmer/Colder) W/W 4.6/5.4/3.8 4.4/5.1/3.5
Application Area m
2
12-18 16-24
Indoor
Unit
Indoor Unit Model
GWH09QC-K6DNC2A/I
GWH09QC-K6DND2A/I
GWH12QC-K6DNC2A/I
GWH12QC-K6DND2A/I
Indoor Unit Product Code
CB439N14100
CB461N06600
CB439N14200
CB461N06500
Fan Type Cross-ow Cross-ow
Fan Diameter Length(DXL) mm Ф98X633.5 Ф98X633.5
Cooling Speed r/min 1300/1200/1120/1050/980/920/750 1350/1200/1120/1050/980/920/750
Heating Speed r/min 1300/1200/1140/1080/1020/960/900 1350/1200/1140/1080/1020/960/900
Fan Motor Power Output W 20 20
Fan Motor RLA A 0.09 0.09
Fan Motor Capacitor μF / /
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Evaporator Pipe Diameter mm Ф5 Φ5
Evaporator Row-n Gap mm 2-1.4 2-1.4
Evaporator Coil Length (LXDXW) mm 635X22.8X306.3 635X22.8X306.3
Swing Motor Model MP24EB/MP24HF MP24EB/MP24HF
Swing Motor Power Output W 1.5/1.5 1.5/1.5
Fuse Current A 3.15 3.15
Sound Pressure Level(SH/H/MH/M/ML/L/SL) dB (A) 41/39/37/35/33/31/24 43/39/37/35/34/32/25
Sound Power Level(SH/H/MH/M/ML/L/SL) dB (A) 56/53/52/50/48/46/39 58/53/52/50/48/46/46
Dimension (WXHXD) mm 845X289X209 845X289X209
Dimension of Carton Box (LXWXH) mm 918X278/364 918X278/364
Dimension of Package(LXWXH) mm 931X281X379 931X281X379
Net Weight kg 10.5 11
Gross Weight kg 12.5 13
