127
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH12QC-K6DNA1D/I GWH09QB-K6DNB6E/I GWH09QB-K6DNC2E/I
Product Code CB419N15500 CB435N09600 CB439N13300
1 Front Panel 20022475 20000300050T 20000300068S 1
2 Display Board 30565231 30565281 30565281 1
3 Front Case Assy 20022489 00000200040 00000200040 1
4 Guide Louver 10512492 1051276301 1051276301 1
5 Air Louver (left) 10512725 10512720 10512720 1
6 Swing Lever 10582459 10582460 10582460 1
7 Helicoid Tongue 26112436 26112508 26112508 1
8 Rear Case assy 00000100092 20022682 20022682 1
9 Drainage Hose 05230014 0523001408 0523001408 1
10 Ring of Bearing 26152022 26152022 26152022 1
11 O-Gasket sub-assy of Bearing 7651205102 7651205102 7651205102 1
12 Evaporator Support 2 24212179 24212180 24212180 1
13 Evaporator Assy 011001060162 0110010009505 0110010009505 1
14 Wall Mounting Frame 01252484 01252043 01252043 1
15 Cross Flow Fan 10352056 10352059 10352059 1
16 Motor Press Plate 26112516 26112373 26112373 1
17 Fan Motor 1501214606 150120874 150120874 1
18 Connecting pipe clamp 2611216401 2611216401 2611216401 1
19 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
20 Stepping Motor 1521210710 1521210704 1521210704 1
21 Crank 73012005 73012005 73012005 1
22 Stepping Motor 1521210108 1521212901 1521212901 1
23 Air Louver(right) 10512726 10512740 10512740 1
24 Electric Box Assy 100002061123 100002062338 100002062338 1
25 Air Louver 1 10512727 10512739 10512739 1
26 Axile Bush 10542036 10542036 10542036 1
27 Terminal Board 42011233 42011233 42011233 1
28 Jumper 4202021906 4202021908 4202021908 1
29 Main Board 300002060230 300002060228 300002060228 1
30 Shield Cover of Electric Box Cover 01592150 01592150 01592150 1
31 Electric Box Cover Sub-Assy 0140206501 0140206501 0140206501 1
32 Electric Box Cover 2011220701 20112207 20112207 1
33 Power Cord / / / /
34 Connecting Cable 4002052317 4002052317 4002052317 0
35 Connecting Cable / / / /
36 Remote Control 305001060023 305001060023 305001060023 1
37 Cold Plasma Generator 1114001603 1114001603 1114001603 1
38 Detecting Plate 30110144 30110154 30110154 1
To Next Page
