167
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH24QE-K6DNB4E/I GWH24QE-K6DNA5X/I GWH24QE-K6DND2I/I
Product Code CB434N12403 CB425N15400 CB461N06800
1 Front Panel Assy 20000300029T 00000300021 0000030023502 1
2 Filter Sub-Assy 1101200703 1101200703 1101200703 2
3 Screw Cover 2425245301 2425245301 2425245302P 3
4 Front Case Assy 00000200043 00000200013 0000020017301 1
5 Swing Lever 10512743 10512743 10512743 1
6 Air Louver 10512744 10512744 10512744 3
7 Helicoid Tongue sub-assy 26112384 26112384 26112384 1
8 Left Axile Bush 10512037 10512037 10512037 1
9 Rear Case assy 22202736 22202736 22202736 1
10 Rubber Plug (Water Tray) 76712012 76712012 76712012 1
11 Ring of Bearing 26152025 26152025 26152025 1
12 O-Gasket sub-assy of Bearing 76512051 76512051 76512051 1
13 Cross Flow Fan 10352057 10352057 10352057 1
14 Evaporator Support 24212178 24212178 24212178 1
15 Evaporator Assy 01100100007303 01100100007303 011001000095 1
16 Wall Mounting Frame 01252229 01252229 01252229 1
17 Motor Press Plate 26112515 26112515 26112515 1
18 Fan Motor 15012145 15012145 15012136 1
19 Connecting pipe clamp 26112514 26112514 26112514 1
20 Drainage Hose 0523001405 0523001405 0523001405 1
21 Stepping Motor 1521240212 1521240212 1521240212 1
22 Crank 73012005 73012005 73012005 1
23 Air Louver 1 10512741 10512741 10512741 2
24 Air Louver 10512742 10512742 10512742 1
25 Stepping Motor 1521210704 1521210704 1521210704 1
26 Guide Louver 1051232001 1051273802 1051232002P 1
27 Axile Bush 10542036 10542036 10542036 2
28 Electric Box 2011221105 2011221105 2011221104 1
29 Terminal Board 42011233 42011233 42011233 1
30 Electric Box Cover 2 20112210 20112210 2011221004P 1
31 Main Board 300002060242 300002060239 300002060785 1
32 Display Board 30565260 30565260 30565308 1
33 Shield Cover of Electric Box 01592139 01592176 01592176 1
34 Electric Box Cover 20112209 20112209 2011220901 1
35 Jumper 4202021925 4202021916 4202021921 1
36 Lower Shield of Electric Box 01592139 01592139 01592139 1
37 Electric Box Assy 100002069071 100002062358 100002062958 1
38 Power Cord / / / /
39 Connecting Cable 4002052317 4002052317 4002052317 0
40 Connecting Cable / / / /
41 Temperature Sensor 3900031302 3900031302 3900031302 1
42 Remote Controller 305001060023 305001060023 305001000081 1
43 Detecting Plate 30110144 30110144 30110144 1
