171
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
QtyGWH24QE-K6DNC2E/I
Product Code CB439N13001
1 Front Panel 20000300071S 1
2 Filter Sub-Assy 1101200703 2
3 Screw Cover 2425245301 3
4 Front Case Assy 00000200043 1
5 Air Louver(Manual) 10512737 3
6 Helicoid Tongue 26112513 1
7 Left Axile Bush 10512037 1
8 Rear Case assy 22202570 1
9 Rubber Plug (Water Tray) 76712012 1
10 Ring of Bearing 26152025 1
11 O-Gasket of Cross Fan Bearing 76512203 1
12 Cross Flow Fan 10352057 1
13 Evaporator Support 24212178 1
14 Evaporator Assy 01100100007303 1
15 Wall Mounting Frame 01252229 1
16 Motor Press Plate 26112515 1
17 Fan Motor 15012145 1
18 Connecting pipe clamp 26112514 1
19 Drainage Hose 0523001405 1
20 Stepping Motor 1521240212 1
21 Crank 73012005 1
22 Guide Louver 1051232001 1
23 Axile Bush 10542036 2
24 Electric Box 2011221105 1
25 Terminal Board 42011233 1
26 Electric Box Cover2 20112210 1
27 Main Board 300002060917 1
28 Display Board 30565278 1
29 Shield Cover of Electric Box 01592176 1
30 Electric Box Cover 20112209 1
31 Jumper cap 4202021925 1
32 Lower Shield of Electric Box 01592139 1
33 Electric Box Assy 100002069699 1
36 Temperature Sensor 3900031302 1
37 Remote Controller 305001000111 1
38 Rear Grill Sub-assy / /
37 Shield Cover of Electric Box Cover 01592176 1
38 Electric Box Cover 20112209 1
39 Detecting plate(WIFI) 30110144 1
