173
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
NO.
Description
Part Code
Qty
GWH09QB-K6DNA1E/O
Product Code CB419W15800 CB419W15801
1 Electric Box Assy 100002061319 100002061410 1
2 Electric Box 20113034 20113034 1
3 Main Board 300027060176 300027060177 1
4 Reactor 43130184 43130184 1
5 Terminal Board 422000060016 422000060016 1
6 Wire Clamp 71010103 71010103 2
7 Front Grill 22413049 22413049 1
8 Front Panel 01533034P 01533034P 1
9 Axial Flow Fan 10333004 10333004 1
10 Chassis Sub-assy 017000060096 017000060102 1
11 Brushless DC Motor 1501308511 1501308511 1
12 Top Cover Sub-Assy 000051060006 000051060006 1
13 Motor Support 01703104 01703104 1
14 Condenser Assy 011002060205 011002060205 1
15 Rear Grill 01473009 01473009 1
16 Capillary Sub-assy 030006060170 030006060170 1
17 Cut off Valve 071302391 071302391 1
18 Big Handle 262334332 262334332 1
19 Cut off Valve 071302391 071302391 1
20 Valve Support 0171314201P 0171314201P 1
21 Right Side Plate Sub-Assy 0130317801 0130317801 1
22 4-Way Valve Assy 030152060087 030152060087 1
23 Clapboard Sub-Assy 0123338502 0123338502 1
24 Magnet Coil 4300040050 4300040050 1
25 Compressor and Fittings 009001060050 009001060050 1
26 Electrical Heater / / /
27 Electrical Heater (Chassis) 7651000414 / 1
28 Drainage Connecter 06123401 06123401 1
