178
Installation and Maintenance
Service Manual
Above data is subject to change without notice.
No.
Description
Part Code
Qty
GWH18QD-K6DNA1D/O
Product Code CB419W15600 CB419W15601
1 Front Grill 22413045 22413045 1
2 Front Panel 01535013P 01535013P 1
3 Drainage Connecter 06123401 06123401 1
4 Chassis Sub-assy 02803270P 02803270P 1
5 Drainage Joint 06813401 06813401 1
6 Compressor and Fittings 009001060006 009001060006 1
7 Magnet Coil 4300876704 4300876704 1
8 4-Way Valve Assy 030152060089 030152060089 1
9 Cut off Valve Assy 030164000042 030164000042 1
10 Cut off Valve Sub-Assy 0713506803 0713506803 1
11 Valve support assy 01715010P 01715010P 1
12 Right Side Plate 0130509402P 0130509402P 1
13 Valve Support 22245002 22245002 1
14 Handle 26233053 26233053 1
15 Wire Clamp 26115004 26115004 1
16 Rear Grill 01473043 01473043 1
17 Condenser Assy 011002060187 011002060187 1
18 Reactor / / /
19 Clapboard Sub-Assy 01233153 01233153 1
20 Coping 012049000007P 012049000007P 1
21 Supporting Board(Condenser) 01795010 01795010 1
22 Motor Support Sub-Assy 01705036 01705036 1
23 Fan Motor 1501506402 1501506402 1
24 Axial Flow Fan 10335008 10335008 1
25 Left Side Plate 01305093P 01305093P 1
26 Left handle 26233053 26233053 1
27 Electric Box Assy 100002061293 100002061293 1
28 Wire Clamp 71010003 71010003 1
29 Terminal Board 422000060009 422000060009 1
30 Electric Box 20113027 20113027 1
31 Radiator 49013060 49013060 1
32 Main Board 300027060172 300027060172 1
33 Insulated Board (Cover of Electric Box) 20113003 20113003 1
34 Temperature Sensor 3900030901 3900030901 1
35 Electronic Expansion Valve assy 030174060025 030174060025 1
To Next Page
